Special Application Motor
Wolong Special Application Motor Full Range
Related products
| Item | Coal Shearer Three-Phase Induction Motor | Roadheader-Bolter Three-Phase Induction Motor | Scraper Conveyor Three-Phase Induction Motor |
|---|---|---|---|
| Cooling Method | IC37W | IC37W | IC37W |
| Power Range | 20 ~ 1250 kW | 36 ~ 540 kW | 160 ~ 1600 kW |
| Speed Range | 750–1500 rpm | 750–1500 rpm | 1500 rpm |
| Frequency | 50Hz fixed; 5–100Hz variable frequency | 50Hz | 50Hz fixed; variable frequency optional |
| Voltage Range | 380–3300 V | 380–3300 V | 660–11000 V |
| Protection Grade | IP56, IP67 | IP56, IP67 | IP56, IP67 |
| Explosion-proof Type | Ex db I Mb | Ex db I Mb | Ex db I Mb |
| Rotor Material | Copper bar | Copper bar | Copper bar |
| Mounting Type | B10 | B10 | IMB3, IMB35, IMB10 |
| Bearing Type | Rolling bearing | Rolling bearing | Rolling bearing |
| Executive Standard | GB, IEC, EN | GB, IEC, EN | GB, IEC, EN |
| Certifications | IEC Ex, ATEX, CCC, MA | IEC Ex, ATEX, CCC, MA | IEC Ex, ATEX, CCC, MA |
| Ambient Temperature | 0℃ ~ +40℃ | 0℃ ~ +40℃ | 0℃ ~ +40℃ |
| Relative Humidity | ≤95% (at 25℃) | ≤95% (at 25℃) | ≤95% (at 25℃) |
| Altitude | ≤1000m (standard); 1000–3000m (customized) | ≤1000m (standard); 1000–3000m (customized) | ≤1000m (standard); 1000–3000m (customized) |
